An embedded database system is a database management system (DBMS) which is tightly integrated with an application software that requires access to stored data, such that the database system is “hidden” from the application’s end-user and requires little or no ongoing maintenance. (Source: Wikipedia.org)

In this post I am going to show you how you could implement an embedded database within a Java application.

  1. Download the Platform-Independent Zip.
  2. Extract it into your library folder on your local installation.
  3. Start Eclipse.
  4. Create a new project.
  5. Add the h2*.jar to the classpath of your new project.
  6. Setup a entry point of your application as you create a new class containing the following code:
    import java.sql.Connection;
    import java.sql.DriverManager;
    import java.sql.ResultSet;
    import java.sql.Statement;

    public class Start {

    	/**
    	 * @param args
    	 */
    	public static void main(String[] args)
    	{
    		try
    		{
    			Class.forName("org.h2.Driver");
    	        Connection con = DriverManager.getConnection("jdbc:h2:~/test", "test", "" );
    	        Statement stmt = con.createStatement();
    	        //stmt.executeUpdate( "DROP TABLE table1" );
    	        stmt.executeUpdate( "CREATE TABLE table1 ( user varchar(50) )" );
    	        stmt.executeUpdate( "INSERT INTO table1 ( user ) VALUES ( 'Claudio' )" );
    	        stmt.executeUpdate( "INSERT INTO table1 ( user ) VALUES ( 'Bernasconi' )" );

    	        ResultSet rs = stmt.executeQuery("SELECT * FROM table1");
    			while( rs.next() )
    			{
    			    String name = rs.getString("user");
    			    System.out.println( name );
    			}
    			stmt.close();
    			con.close();
    		}
    		catch( Exception e )
    		{
    			System.out.println( e.getMessage() );
    		}
    	}
    }
  7. Run it and see the output in the Eclipse Console. If everything works fine the output should be like:
  8. If you additionally want to create a *.jar file for sharing your project to another computer you have to take care that the lib h2*.jar is also exported. The exported jar file will be ca. 1-2 mb. See the following steps below:
  9. Right click on the projects home directory.
  10. Select Export.
  11. Select Runnable Jar file from the Java folder.
  12. Note: If you try to start the exported *.jar on another machine you won’t see any output. Therefore you have to check the home directory for new generated files. On WindowsXP: C:\Dokumente und Einstellungen\[USER]\test.h2.db. If there is a file called like that. Everything worked fine!
